Shenzhen Pad Printing Plate Technology: Material Selection to Etching

Shenzhen isn't just known for its manufacturing—it's where innovation and precision come together. The city is a leader in pad printing, a technique that’s perfect for printing on small, uneven surfaces. That’s why it’s so important in industries like electronics, toys, cosmetics, and medical devices. At the heart of pad printing is the steel plate (also called a cliché or printing plate), which plays a huge role in both the quality of the prints and how efficiently the production runs. In this article, we’ll take a closer look at the technology behind Shenzhen’s pad printing plates, covering material choices, surface finishes, and the etching process.

1. Material Selection: Bearing Steel, Oil Steel, and Chrome Steel

Pad printing steel plates are far from ordinary. They need to possess high hardness, exceptional wear resistance, toughness, and corrosion resistance. More than that, they must have a fine microstructure to withstand the repeated scraping of the squeegee, without compromising print quality. In Shenzhen, there are three main materials used for steel plates:

Bearing Steel (GCr15) — The Industry Standard

Characteristics: Bearing steel is the most widely used material for pad printing plates, and for good reason. Its performance is unmatched. After heat treatment, it reaches a hardness of HRC60-62 while maintaining excellent toughness and fatigue resistance. Its uniform internal structure is perfect for precise etching.

Applications: Bearing steel is the go-to choice for applications requiring high precision and durability. It’s used in everything from the fine details on mobile phone keys to logos on Bluetooth earphones, instrument panels, and medical device scales. In Shenzhen’s bustling 3C electronics industry (computers, communications, and consumer electronics), bearing steel is the preferred material for high-quality prints.

Oil Steel (O1, 9CrWMn) — A Cost-Effective Option

Characteristics: Oil steel, like O1 or 9CrWMn, is a low alloy tool steel with a slightly lower hardness than bearing steel (HRC58-60). It has excellent hardenability, minimal heat treatment distortion, and is easy to machine and polish.

Applications: This material is ideal for products that don’t require extremely high hardness or large-scale production. Think toy parts, everyday household items, and basic electrical appliance casings.

Chrome Steel (DC53/SKD11) — For Special Needs

Characteristics: Chrome steel, such as DC53 or SKD11, is renowned for its extreme hardness and wear resistance (HRC62-63). However, its microstructure contains coarser carbide particles, so it might not etch as finely as bearing steel.

Applications: Chrome steel is used for specialized needs, like products requiring high wear resistance or large-volume prints. In Shenzhen, it's used more for specific projects that demand durability, such as printing abrasive inks with rough textures.

Conclusion: In Shenzhen, bearing steel (GCr15) is the dominant choice for high-end pad printing, thanks to its perfect balance of performance and durability. Oil steel and chrome steel have their place for more specialized applications, offering a great balance between cost and functionality.

2. Surface Finishing: Mirror Finish vs Satin Finish

The surface of the steel plate plays a crucial role in ink transfer, print clarity, and the longevity of the pad head. Shenzhen manufacturers offer two main surface treatments, each designed to meet different needs:

Mirror Finish — A Perfect, Glass-Like Surface

Characteristics: The mirror finish is achieved by polishing the steel plate to an ultra-smooth, reflective surface with incredibly low roughness (Ra ≤ 0.01μm). The benefits are immediately apparent:

Reduced Squeegee Resistance: A smoother surface means less friction, which reduces wear on both the squeegee and the steel plate, helping them last longer.

Better Ink Release: The smooth surface allows the squeegee to effectively remove ink from the non-printing areas, preventing unwanted marks and ink splatter.

Crisp, Clear Prints: The mirror finish provides an excellent foundation for precise etching, resulting in sharp, clean edges without any burrs.

Protects the Pad Head: The smoother the steel plate, the less friction there is between it and the pad head, which helps extend the life of both.

Satin Finish — Durable and Practical

Characteristics: Satin finish offers a smooth, semi-gloss surface, slightly less shiny than the mirror finish but still smooth enough for high-quality printing (Ra 0.1-0.4μm). Its key benefits include:

Improved Ink Adhesion: The fine texture of the satin surface helps ink adhere better, particularly for high-viscosity inks or high-speed printing.

Resilient to Scratches: Satin finish can hide minor scratches that occur during use, making the steel plate more durable and longer-lasting.

Recommendation: For high-precision electronics, the mirror finish is usually the best choice. However, for applications where surface smoothness is less critical, or when better ink adhesion is needed, satin finish is an excellent option.

3. Etching Depth: The Art of Precision

Etching depth is one of the most important factors in making pad printing steel plates. It’s not a one-size-fits-all measurement but something that must be adjusted based on the product material, background color, and ink properties.

Product Material and Shape:

For rough or porous surfaces (such as certain plastics, leather, or untreated wood), deeper etching (35-40μm) is needed to hold more ink and ensure the print is fully saturated and clear.

For smooth, non-porous surfaces (like ABS, PC, glass, or metal), a shallower etching depth (15-25μm) is sufficient to achieve sharp, clear graphics.

Background Color and Coverage:

When printing light-colored ink on a dark background (such as white ink on black plastic), deeper etching (40-50μm) is necessary to ensure full coverage.

When printing dark-colored ink on a light background (such as black ink on white plastic), a shallower etching (15-25μm) will do the job.

Material Impact:

Different materials etch at different rates. Skilled technicians adjust the etching time and depth based on the steel’s characteristics, ensuring the perfect result every time.

Conclusion: Shenzhen manufacturers use their extensive experience and customer feedback to determine the best etching depth for each project. This flexibility allows them to achieve optimal print results, tailored to specific needs.

Final Thoughts

Shenzhen’s pad printing plate technology is a testament to China’s manufacturing expertise. From the selection of the highest-quality bearing steel to the precise mirror-finish surface treatments and the careful control of etching depth, every detail reflects the city’s commitment to quality and precision. Companies like Tefisen, with their years of experience, produce steel plates that power industries ranging from electronics to medical devices, helping create products with crisp, clear, and durable prints. For pad printing manufacturers, understanding these technical nuances is crucial for improving product quality and staying competitive in a fast-paced industry.
